AR-500

The AR-500, with a stunning lift capacity of 500 kg, makes it the most powerful Ceiling Hoist in the world!

The AR-500 is used for a safe and respectful movement of bariatric care recipients. The high-quality Ceiling Hoist is extremely low noise in use, both in lifting and moving through the rail. Through the design, the Ceiling Hoist looks tenderly. The standard features are:

  • An advanced battery protection system.
  • Auto stand-by when not used for a while.
  • No power consumption in stand-by.
  • Slow start and stop function for high lifting comfort.
  • Prepared for an electric spreader bar.
  • Charged by hand control, using a magnetic wall charger.
  • Double steering trolley for an easy and smooth transfer through the rail.
Patient Lifting Solutions AR-500 Ceiling Hoist system for bariatric care
Technical specifications
Lift capacity (swl) 500 kg
Dimensions 496 x 340 x 188 mm
Weight 26,7 kg
Power Battery charged; 24 V/DC, 20 Ah
Minimal belt length 140 mm
Maximal belt length 2260 mm
Lifting velocity 32-70 mm/sec
Lifts per full charge >30 @500 kg
Charging time 8 Hours
Dimensions of Patient Lifting Solutions AR-500 Ceiling Hoist for bariatric care
